This machine is the automatic special production line used for flat bars channel steel marking, punching, and shearing mainly in the field of angle steel tower industry, electric power fittings, structure storage facilities, and steel structure construction industries etc.
• Good rigidity, compact structure, optimal workpiece arrangement and high using rate of workpiece.
• With CNC and serve motor achieves it high efficiency and stable working accuracy.
• The key hydraulic pneumatic and electrical elements are all imported from Germany, Japan, and South Korea etc.
• Easy programming, only need to input the data of workpiece, including size, hole diameter, stadia accuracy and quantity. Or use the programming data created by lofting software.
• Friendly computer interface can show workpieces' figure, easy for operation.
• Equipped with self-diagnostic function.
| Model | PL065 |
| Flat Bar Size | 40x4-100x10 |
| Max. punching capability | 25 x 50(Oval hole)x10, Ø26*10. |
| Channel Steel Size | 8#-14# |
| Nominal punching force (KN) | 750 |
| Marking force (KN) | 650 |
| Shearing force (KN) | 750 |
| Max length of workpiece (mm) | 8000 |
| Punches numbers of each side | 3(2 round hole+1 oval hole) |
| Marking Station | 1 |
| Dimensions of Character | 14*10*19 |
| Max. Feeding speed (m/min) | 60 |
| Number of CNC axis | 2 |
| Programming model | Keyboard enter, USB interface input, CAD graphics programming |
| Overall dimensions (mm) | 18700x 5200 x 3000 |
